Our range of spare parts and accessories to suit Off Road Drift II Go Karts. A variety of parts for many models of Go Karts
We at Go Carts Australia endeavour to supply all parts for the Carts we sell and will also help you find that part yourve been looking for but unable to find.. I hold a full range of parts for several different models so don't hesitate to contact me at simon@gocartsaustralia.com.au
$25.00
Air Filter cartridge for the 6.5hp 196cc engine for all Off Road Drift Go Karts. This is a replacement cartridge and can easily be installed
$25.00
Air Filter cartridge for the 9 hp 270 cc engine for all Off Road Drift Go Karts. This is a replacement cartridge and can easily be installed
$49.00
Air Filter Cartridge Upgrade to suit 5.5 hp and 6.5 hp Engines
increased airflow and horsepower
60 mm inside diameter Adapter 61 mm outside diameter 25 mm inside diameter
Venturi Adapter [If you are looking to adapt this item to another filter or engine, stud spacing is 43 mm centre to centre, 6 mm studs. Centre of venturi has a hole 25.5 mm diameter. Outer diameter is 61 mm
$20.00
Air Filter housing for 6.5 hp 196 cc and 5.5 hp 168 cc Engines run on all Off Road Drift Go Karts. Does not include air filter cartridge. These can be easily installed at home. Made of black plastic$95.00
Staggered Spline rear axle for models GK200, GK200N, GK270N
Length 870 mm and Shaft Diameter is 27 mm Bearing seat to end of axle 165 mm Inner Spline Length 33 mm (118 mm from end of axle) Thread length 33 mm (85 mm from end of axle) Outer Spline length 32 mm (24 mm from end of axle) Thread length at end of axle 25 mm.
Thread 22 mm 1.5 p metric fine
Please contact me for a freight quote at info@gocartsaustralia.com.au or the item can be collected from my store
$115.00
Rear Drive Axle for Off Road Drift II Go Cart
Suits Models suffix LW
Axle Length 850 mm Bearing seat distance 145 mm from Axle end, Spline of axle length 90 mm (Axle thread at 26 mm from end of axle)
Please contact me for a freight quote at info@gocartsaustralia.com.au or the item can be collected from my store
Sold Out
Axle kit for the home Go Kart builder. Comes complete with Axle, Front wheel hubs with bearings Rear wheel hubs Chain hub and rotor hub, 2 front wheel bushes and a keyway
One end is splined and one end has a keyway
Axle Length 870 mm
$95.00
Rear Axle with keyway on drive side and spline on the brake side
Rear drive axle to suit models Drift II 6.5 hp 196 cc and Bulldog 270 cc 9 hp Karts
Please contact me for a freight quote at info@gocartsaustralia.com.au 0402229355 or the item can be collected from our store
$15.00
Rear Axle Bearings to suit Off Road Go Kart
Model older model
Sold Out
Rear Axle Bearings to suit Off Road Go Cart
Model GK200 GK200N & GK270N
Bearing 6205RS
Sold Out
Front Stub Axle Bearings to suit Off Road Go Cart
Model GK200 or GK200N or GK270N
Diameter 35 mm x 10 mm Centre 13 mm
Bearing 6003RS
$6.00
Bearing
Diameter 28 mm 8 mm width 12 mm centre hole
$39.00
Torque converter drive belt
18.8 mm wide single tapered one side 70 tooth 669 mm length
$15.00
Hydraulic Brake Caliper mounting Bracket
Caliper mounting holes 62 mm centre to centre
39 mm from hole centre to chassis mount
$40.00
Please note these are in stock
Text 0402229355 if you have problems ordering
Cable Brake Caliper for Drift II Off Road Go Carts to suit these style brake pads
Distance between mounting bracket holes centre to centre is 52mm
Please note hydraulic calipers are NOT a straight forward replacement for these brake Calipers
$49.00
Hydraulic Brake Caliper for Drift Go Karts. Consists of only the Caliper for the Hydraulic brake assembly. These callipers are replacement for carts already fitted with hydraulic brakes but are perfect for slowing these carts. They are fitted with brake pads and contain no asbestos and can be easily replaced when required.
Mounting holes 63 mm centre to centre
$120.00
Hydraulic Disc Brake assembly complete with caliper, hose and brake lever for butterfly steering wheel. Designed to increase brake capacity on Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 140 cm from lever to caliper. Please note these are a replacement part and may require adaptations to fit some karts not originally fitted with Disc brakes
Note for replacement Lever has an 6 mm bolt to connect the hose and the Caliper is heavy duty cast with attachment holes at 40 mm centre to centre
$99.00
Heavy duty Hydraulic Disc Brake assembly complete with caliper, hose and brake lever for butterfly steering wheel. Designed to increase brake capacity on Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 166 cm from lever to caliper. Please note these are a replacement part and may require adaptations to fit some karts not originally fitted with Disc brakes
Note for replacement Lever has an 8mm bolt to connect the hose and the Caliper is heavy duty cast with attachment holes at 63mm centre to centre
$99.00
Hydraulic Disc Brake assembly complete with caliper, hose and foot pedal leverage bracket for attachment to pedal control on Go Karts. Designed to increase brake capacity on all Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 120 cm from foot pedal to caliper.
$35.00
Brake Rotor for Hydraulic Disc brakes
Diameter 160 mm 6 stud hole pattern Centre hole 39 mm Stud holes 25 mm apart centre to centre 3 mm thickness
$40.00
Brake Rotor for Hydraulic Disc brakes
Diameter 160 mm 6 stud hole pattern Centre hole 33 mm . Stud holes 22 mm apart centre to centre 2 mm thickness
$15.00
1 x pair Brake Pads to suit Cable type brake calipers. They contain No asbestos and these pads are easily replaced at home
$25.00
Brake Pads to suit Alloy Hydraulic brake calipers. These can be easily replaced at home and contain NO asbestos
Sold as a pair
$25.00
Brake Pads to suit Hydraulic disc brake calipers. These can be easily replaced at home and contain NO asbestos
Sold as a pair
$39.00
Front left hand Drum Brakes for Early Drift II Models. It comes complete with brake shoes and I do stock replacement brake shoes. Made from cast iron these are a well constructed unitSold Out
$89.00
Front Bumper Assemble. Attaches to most Off Road Drift II Go Carts. Easily to install
Distance between attachment Brackets centre to centre is.approx 245 mm..
Black Only
Please contact me for a freight quote 0402229355 or info@gocartsaustralia.com.au or the item can be collected from my store
$10.00
Rear swing arm bush
43 mm long with a 10 mm centre hole
$10.00
Rear Axle spacers
24.8 mm inside diameter 32 mm outside diameter 17 mm width 3.3 mm thick
$20.00
Brake Cable for butterfly steering wheel and standard brake calipers. This consists of an inner and outer cable
Approx. length of outer cable 120 cm
$25.00
Hydraulic brake hose
Length of hose 160 cm
Diameter of coupling hole 10 mm
2015-11 32 mm A072822 DOT SAE J101 /8 ID HL
Made in KH Hose
$25.00
Throttle Accelerator cable for the Bulldog Go Cart Foot Control
Approximate length 220 cm Outer Cable
$20.00
Throttle Accelerator cable for the butterfly steering wheel Go Cart
Approximate length 180 cm Outer Cable
For Drift II Go Karts
$15.00
Fuel cap petrol resistant plastic screw thread type
$39.00
Carbie to suit both 6.5 hp engines. Non adjustable fuel mixture screw Easily replaced at home
Does not come with engine gasket
$45.00
Carbie to suit both 9 hp engines. Non adjustable fuel mixture screw Easily replaced at home
Does not come with engine gasket
$3.50
Drive Chain joiner for Drift II Go Kart. 420
For 6.5 hp engines We also have Chain to suit that can be purchased by the length
$5.00
Drive Chain cut to length and sold by the 100 mm (10 cm) approx 4 links
Standard length of chain normally 30 links 770 mm long 41 Pitch
I have noticed some Karts require longer length chain so I now stock it by the roll and I stock chain joiners to suit
Chain drive for 6.5 hp go karts
Chain Pitch Centre Pin 12.45 mm
Roller diameter 7.66 mm
Roller width 6.64 mm
Pin Thickness 3.93 mm
Side Bar Thickness 10.21 mm
Side Bar Thickness 1.45 mm
$35.00
Chain drive for 6.5 hp go carts
approx. 30 links 760 mm total length 41 Pitch
Chain Pitch Centre Pin 12.45 mm
Roller diameter 7.66 mm
Roller width 6.64 mm
Pin Thickness 3.93 mm
Side Bar Thickness 10.21 mm
Side Bar Thickness 1.45 mm
$39.00
Chain for the Bulldog 9 hp Engine
Length 900 mm
Chain Pitch Centre Pin 12.49 mm
Roller diameter 8.37 mm
Roller width 8 mm
Pin Thickness 4. mm
Side Bar width 10.53
Side Bar Thickness 1.58 mm
Sold Out
$55.00
Centrifugal Dry Clutch 10 tooth sprocket, fits a 19 mm shaft, diameter 110 mm, Length of centre shaft bush 59 mm and the internal clutch springs can be replaced
- The friction material & arrestor spring(s)
- The transmission plate & central shaft. (central shaft not shown. Picture below shows friction material and spring installed)
In the picture above you can see the friction material installed onto the transmission plate. You can see the transmission plate splines in the centre of the plate. The central shaft (not shown) slots into these splines and slides onto the crankshaft of the engine. It rotates with the engine because it is keyed and the key slots into the keyway on the crankshaft.
The drum sits over this material and is large enough so that the material does not contact the drum when it is fitted. You can rotate the drum freely when the unit is assembled as the friction material does not contact the drum.
As the speed of the crankshaft rotation increases (RPM increases) there is more and more centrifugal force on the friction material.
The spring holds them together in a tight circle and they do not touch the drum.
As the force pushing the friction material away from the centre increases to a point that it is greater than the force applied by the spring, the friction material starts to move outwards and contacts with the drum.
This begins to happen somewhere between 1500rpm and 1800rpm on the standard DRY CLUTCHES. At this point, the drum is still slipping on the friction material because the amount of force is not great enough to overcome the friction from the back wheels. The more weight, the more friction. When the drum slips, it creates heat. This is the biggest CON for the Dry Centrifugal Clutch.
NOTE: DRY CLUTCHES SHOULD NOT BE IDLED!
ONE MORE IMPORTANT THING TO NOTE IS THAT AFTER THE FIRST USE, SOME HEAT WILL INEVITABLY BE TRANSFERRED TO THE SPRING AND IT WILL STRETCH SLIGHTLY. FROM THIS POINT ON, AT IDLE, THE CLUTCH WILL SLOWLY BEGIN TO ENGAGE AT IDLE SPEED - THE HIGHER THE IDLE SPEED, THE MORE THE ENGAGEMENT WHICH WILL ACCELERATE WEAR.
At 2000rpm the friction material has so much centrifugal force applied to it that the spring can no longer arrest the material and it completely contacts the drum. This is considered it's FULLY ENGAGED rpm. Power is now transmitted directly through the chain to the rear drive sprocket and no further heat is created.
$15.00
Replacement centrifugal clutch spring
With the right tools it is easy to replace the spring in the clutch
$129.00
$129.00
$55.00
Drift Trike 10 mm thick Hardened Black Plastic Sleeves
Suit Tyres 22 cm to 23 cm Diameter
Sold as a PAIR
$259.00
Engine 6.5 horse power 196 cc. Pull Start, Unleaded fuel, 4 stroke,
Dimensions (L x W x H) 37 cm x 31.5 cm x 33 cm approx. Bore x Stroke 68 mm x 54 mm Shaft Length x Diameter 45.5 x 19.05 mm Keyway Size 4.78 x 16.36 mm Mounting Hole Dimensions (Diameter) M8 x 20 mm Compression Ratio 8.5:1 Max Power Output 4.8 KW Max Torque 10.8N.m/2500 rpm Type Single-Cylinder, 4-Stroke Displacement 196 cc Fuel Gasoline Fuel Tank 3.6L Package Dimensions (L x W x H) 38 cm x 32.5 cm x 34 cm approx. Package Weight 16 kg approx.
Please contact me for a freight quote at info@gocartsaustralia.com.au or text 0402229355 or the item can be collected from my store
Our range of Off Road Drift, Bulldog and Thunder Go Karts ready to ship via TNT just contact me for a freight quote.
Sold Out
The BULLDOG 270 cc 9 hp BLACK
Note this for a BLACK coloured Go Kart with latest EPA engine
270cc 9 horse power 4 stroke engine with wet clutch, Hydraulic Disc brakes, Foot pedal controls, Front independent suspension with air shock absorbers, 7 inch tubeless tyres all round, 3 point Harness seat belt, Chain drive, Maximum speed approx. 55 klms the engine can be governed to reduce top speed. GK270N This kart comes with the extension frame which gives an approx extra 140 mm extra leg room Please contact me for a freight Quote at 0402229355 or info@gocartsaustralia.com.au or the Kart can be collected from our Store
The box dimensions are 120 cm x 98 cm x 62 cm 120 kg
Dimensions assembled 200 cm L x 99 cm W x 85 cm H
Sold Out
The BULLDOG 270 cc 9 hp RED with latest EPA engine
Note this for a RED coloured Go Kart
270 cc 9 horse power 4 stroke engine with wet clutch, Hydraulic Disc brakes, Foot pedal controls, Front independent suspension with air shock absorbers, 7 inch tubeless tyres all round, 3 point Harness seat belt, Chain drive, Maximum speed approx. 55 klm the engine can be governed to reduce top speed. GK270N This kart comes with the extension frame which gives an approx extra 140 mm extra leg room Please contact me for a freight Quote at 0402229355 or info@gocartsaustralia.com.au or the Kart can be collected from our Store
The box dimensions are 120 cm x 98 cm x 62 cm 120 kg
Dimensions assembled 200 cm L x 99 cm W x 85 cm H
Sold Out
GO KART
Note this is for a BLACK coloured Go Kart with latest EPA engine
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a centrifugal clutch, uses unleaded fuel and has a top speed of approx. 35 to 45 kph. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required
Please contact me for a freight quote at info@gocartsaustralia.com.au or the cart can be collected from my store or text your post code and suburb to 0402229355
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
Sold Out
GO KART
Note this is for a BLACK coloured Go Kart with latest EPA engine
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a TORQUE CONVERTER, uses unleaded fuel and has a top speed of approx. 35 to 45 kph. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required. This model is ideal for the younger children, allowing slower speeds without over heating the clutch
Please contact me for a freight quote at info@gocartsaustralia.com.au or the cart can be collected from my store or text your post code and suburb to 0402229355
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
Sold Out
BLUE GO KART
Note this is for a BLUE Go Kart with latest EPA engine
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a dry centrifugal clutch, uses unleaded fuel and has a top speed of approx. 35 to 45 km. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required
Please contact me for a freight quote on 0402229355 or info@gocartsaustralia.com.au or the cart can be collected from my store
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
Sold Out
BLUE GO KART
Note this is for a BLUE Go Kart with latest EPA engine & torque converter
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a TORQUE CONVERTER, uses unleaded fuel and has a top speed of approx. 35 kms. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required. This model is ideal for the younger children, allowing slower speeds without over heating the clutch
Please contact me for a freight quote on 0402229355 or info@gocartsaustralia.com.au or the cart can be collected from my store
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
Sold Out
RED GO KART
Note this is for a RED coloured Go Kart with latest EPA engine
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a dry centrifugal clutch, uses unleaded fuel and has a top speed of approx. 35 to 45 km. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required
Please contact me for a freight quote on 0402229355 or info@gocartsaustralia.com.au or the cart can be collected from my store
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
Sold Out
RED GO KART
Note this is for a RED coloured Go Kart with latest EPA engine & torque Converter
The standard but most popular Go Kart. Great for the kids yet the adults can still jump on and have a go. It has a 6.5 hp 196 cc 4 stroke engine with pull start. It has a TORQUE CONVERTER, uses unleaded fuel and has a top speed of approx. 35 to 45 km. This model has hydraulic disc brakes and a butterfly steering wheel with lever throttle and brake controls. The engines can be governed to reduce the top speed if required. This model is ideal for the younger children, allowing slower speeds without over heating the clutch
Please contact me for a freight quote on 0402229355 or info@gocartsaustralia.com.au or the cart can be collected from my store
Box Dimensions 85 kg 110 cm x 98 cm x 53 cm
$15.00
Hydraulic Brake Caliper mounting Bracket
Caliper mounting holes 62 mm centre to centre
39 mm from hole centre to chassis mount
$40.00
Please note these are in stock
Text 0402229355 if you have problems ordering
Cable Brake Caliper for Drift II Off Road Go Carts to suit these style brake pads
Distance between mounting bracket holes centre to centre is 52mm
Please note hydraulic calipers are NOT a straight forward replacement for these brake Calipers
$49.00
Hydraulic Brake Caliper for Drift Go Karts. Consists of only the Caliper for the Hydraulic brake assembly. These callipers are replacement for carts already fitted with hydraulic brakes but are perfect for slowing these carts. They are fitted with brake pads and contain no asbestos and can be easily replaced when required.
Mounting holes 63 mm centre to centre
$120.00
Hydraulic Disc Brake assembly complete with caliper, hose and brake lever for butterfly steering wheel. Designed to increase brake capacity on Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 140 cm from lever to caliper. Please note these are a replacement part and may require adaptations to fit some karts not originally fitted with Disc brakes
Note for replacement Lever has an 6 mm bolt to connect the hose and the Caliper is heavy duty cast with attachment holes at 40 mm centre to centre
$99.00
Heavy duty Hydraulic Disc Brake assembly complete with caliper, hose and brake lever for butterfly steering wheel. Designed to increase brake capacity on Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 166 cm from lever to caliper. Please note these are a replacement part and may require adaptations to fit some karts not originally fitted with Disc brakes
Note for replacement Lever has an 8mm bolt to connect the hose and the Caliper is heavy duty cast with attachment holes at 63mm centre to centre
$99.00
Hydraulic Disc Brake assembly complete with caliper, hose and foot pedal leverage bracket for attachment to pedal control on Go Karts. Designed to increase brake capacity on all Off Road Drift Go Karts. The brake pads contain no asbestos and can be easily replaced when required. Length of hydraulic hose approx. 120 cm from foot pedal to caliper.
$35.00
Brake Rotor for Hydraulic Disc brakes
Diameter 160 mm 6 stud hole pattern Centre hole 39 mm Stud holes 25 mm apart centre to centre 3 mm thickness
$40.00
Brake Rotor for Hydraulic Disc brakes
Diameter 160 mm 6 stud hole pattern Centre hole 33 mm . Stud holes 22 mm apart centre to centre 2 mm thickness
$15.00
1 x pair Brake Pads to suit Cable type brake calipers. They contain No asbestos and these pads are easily replaced at home
$25.00
Brake Pads to suit Alloy Hydraulic brake calipers. These can be easily replaced at home and contain NO asbestos
Sold as a pair
$25.00
Brake Pads to suit Hydraulic disc brake calipers. These can be easily replaced at home and contain NO asbestos
Sold as a pair
$39.00
Sold Out
$20.00
Brake Cable for butterfly steering wheel and standard brake calipers. This consists of an inner and outer cable
Approx. length of outer cable 120 cm
$25.00
Hydraulic brake hose
Length of hose 160 cm
Diameter of coupling hole 10 mm
2015-11 32 mm A072822 DOT SAE J101 /8 ID HL
Made in KH Hose
$20.00
Sold Out
Hydraulic Brake Lever with Fluid reservoir
No hose attached. For replacement of damaged hydraulic lever
PLEASE NOTE for replacement purposes the hose attachment bolt on this lever is an 7.9 mm and normally has the alloy brake caliper
Please check before ordering
$40.00
Hydraulic Brake Lever with Fluid reservoir
No hose attached. For replacement of damaged hydraulic lever
PLEASE NOTE for replacement purposes the hose attachment bolt on this lever is an 8mm and normally has the heavy duty Cast brake caliper and 163 cm hose
Please check before ordering
Our range of spare parts and accessories to suit Off Road Drift II Go Karts. A variety of parts for many models of Go Karts
Disclaimer
There are inherent risks involved in using any motorised vehicle, including but not limited to serious physical injury and possible death. This product is not a toy. This product is intended adult riders on a closed track. Go Carts Australia strongly recommends the use of safety equipment at all times while using this product. Appropriate safety equipment would include, but not limited to D.O.T. approved helmet, riders leathers, leather gloves, knee pads, and safety boots. Purchases shall use products at their own risk. Go Carts Australia will not be held liable under any circumstances for incidental or consequential loss or damage or injury, due direct or indirect use of this product including any malfunction from negligence or defect. Go Carts Australia makes no claims as to the suitability of this vehicle for any specific purpose or use. The products on this site are designed for recreational use for a single rider with proper safety equipment. It is not suitable for handicapped persons or persons with limited mental or physical capacities. Although there are no uniform legal age restrictions. Go Carts Australia also recommends that only individuals of legal age use any of the motorised vehicles sold by us. Go Carts Australia also recommends that any minors only use motorised vehicles under Adult supervision and under the guardians own discretion. Purchases should check with their local authorities for area specific rules and regulations. Adult guardian assumes all responsibilities associated with the use of these vehicles by minors.. Customers understand that the use of these products can cause injury or death to themselves or others. To reduce the risk of any such injuries we strongly recommend the use of safety equipment such as an ANSI or Snell approved helmet and knee ads. The buyer holds our company and its agents and affiliates harmless from liability arising out of or relating to the use or ownership of any product. Buyer must obtain her / his own insurance. Purchaser fully accepts responsibility and releases the seller for all and any personal injuries, fatal injuries, any losses, costs and damages incurred as a result of a purchases operation of this item. Purchaser is solely responsible when permitting other riders to ride this item and assumes all responsibility in the event of damages, injuries or fatal injuries etc. Purchaser is responsible for understanding and obeying all local and state laws for operation of these products. Once purchaser submits payment this will serve as purchaser agreement to releasing seller of any and all responsibilities of item such as stated above. Before riding check your local states and city vehicle codes for more information regarding laws. Australian Buyers. This product is for use on closed private tracks only. By placing a bid, you acknowledge that you have and understood, and you agree to the terms and conditions of this Agreement and you represent that you are of legal age (age 18 or old) to enter this agreement and become bound by its items
